Ningbo Xin Chang Machinery Co.,Ltd
상표: 신창
Work Form: One-Body
Type: Stud Welding Machine
인증 : CE
Welder Brand: Soyer (Made in Germany)
Max. Pan Diameter: 500mm
Insulation Grade: IP21
Transport Package: Wooden Case
Specification: 147x80*160cm
Trademark: Xin chang
Origin: Ningbo China
HS 코드: 8515319900
사용자 정의: Available
Style: Vertical
Electric Current: Dc
배송비: Contact the supplier about freight and estimated delivery time.
용접기는 흙손 패널의 스터드 용접용이며 제품 적용 범위는 다음과 같습니다.
| 1 | Model | HB-1000 |
| 2 | Rated volts | 220V± 15% 50HZ |
| 3 | Rated power | 3KVA |
| 4 | Air pressure(Mpa) | 0.6-0.8 |
| 5 | Insulation grade | F |
| 6 | Welding cylinder stroke(mm) | 50 |
| 7 | Ajustment range of Volts(V) | 40-180 |
| No. | Name | Model | QTY | Origin |
| 1 | Machine frame | 1425X700X1250 | 1 | Self-made |
| 2 | Motion control device | HT-AA1-1A | 1 | TRIO,UK |
| 3 | Air cylinder of slider | SMC16-50 | 1 | JAPAN |
| 4 | Motion module | 1000 | 1 | HIWIN |
| 5 | Welding gun | HB-002 | 1 | Self-made |
| 7 | Welder | HB-5000 | 1 | |
| 8 | Servo motor | 750W | 1 | Tama Kawa, Japan |
| 9 | HMI | AHT00058 | 1 | WEINVIEW |
| 10 | Driver | 400 | 1 | INVT |
| 11 | Postioning die | 2 | Self-made | |
| 12 | Stud feeding device | M4X6 | 1 | Self-made |
| 13 | Frame of stud feeding | 500X300X650 | 1 | Self-made |
