Ningbo Xin Chang Machinery Co.,Ltd
상표: 신창
지원에 대한 지원: 5set/Month
A. 주요 기능 및 특징:
| No. | Names | Unit | Specifications | ||
| CB63 | CB85 | CB100 | |||
| 1 | Nominal Pressure | KN | 630 | 850 | 1000 |
| 2 | Stroke of slide | mm | 40-60 | 40-60 | 40-60 |
| 3 | Stamping Strokes | SPM | 150-300 | 150-300 | 150-300 |
| 4 | Die set height | mm | 250-300 | 250-300 | 270-320 |
| 5 | Die height adjustment | mm | 80 | 80 | 80 |
| 6 | Size of table(FB x LR) | mm | 900×1300 | ||
| 7 | Thickness of table | mm | 80 | 90 | 100 |
| 8 | Distance from table to floor | mm | 720 | 760 | 760 |
| 9 | Bottom size of slide (FB x LR) | mm | 730×850 | ||
| 10 | Main motor (power) | KW | 7.5 | 11 | 15 |
| 11 | Air pressure | MPa | 0.5 | 0.5 | 0.5 |
| 12 | Collector length | mm | 1200/1500/2000 | 1200/1500/2000 | 1200/1500/2000 |
| 13 | Aluminum coils max.width | mm | 545 | 615 | 850 |
| 14 | Aluminum coils inner Dia. | mm | ∮75/∮150 | ∮75/∮150 | ∮75/∮150 |
| 15 | Aluminum coils outer Dia. | mm | ∮1000 | ∮1000 | ∮1000 |
| NO. | Content | Manufacturer |
| 1 | Inverter | Inovance |
| 2 | PLC programmer | OMRON |
| 3 | HMI (color screen) | Taiwan Weinview |
| 4 | Rotary encoder | OMRON |
| 5 | Main pneumatic components | AirTAC |
| 6 | Main hydraulic components | YUKEN |
| 7 | Centralized lubrication | IHI |
| 8 | Dual valve of main clutch brake | TACO |
| 9 | Photoelectric safety device | Keli |
